Segment LCD display (white backlight)
Measure 28 electrical parameters including voltage/current/active power/reactive power/frequency/power factor etc.
Active energy/reactive energy/four-quadrant reactive energy metering function, and pulse output port
Standard with 4 DI and 2 alarm output, input/output fully isolated telesignaling & telecontrol function
Optional 1 channel 4~20mA analog transmission output function
Standard with three-phase voltage and current harmonic measurement (2 to 32 times).
Standard 8 time periods, 4 rate statistics functions (multi-rate function)
RS485 com interface, Modbus RTU protocol or TCP/iP (optional).
