3.5 Inch 320*240 TFT display.
Measure 28 electrical parameters including voltage/current/active power/reactive power/frequency/power factor etc.
Active energy/reactive energy/four-quadrant reactive energy metering function, and pulse output port.
Standard with 4 DI and 2 alarm output, input/output fully isolated, telesignaling & telecontrol function.
Optional 1 channel 4~20mA analog transmission output function.
Standard with three-phase voltage and current harmonic measurement (2 to 32 times)
Standard 8 time periods, 4 rate statistics functions (multi-rate function).
With event record function.
RS485 com interface, Modbus RTU protocol & TCP/iP.
